Portable Concrete Pumping Machine

The Portable Concrete Pumping Machine is a trailer-mounted, portable concrete pump for small and medium construction projects, enabling precise delivery for high-rise buildings, bridges, tunnels, and industrial sites.

Send Inquiry Chat Now

Description

Introduction

Features

High-Efficiency Pumping Capacity
The trailer-mounted design, combined with a powerful hydraulic system, enables concrete delivery up to 140 meters horizontally and 270 meters vertically.

Safe and Reliable
Equipped with overload protection, emergency stop, and automatic alarm systems to ensure safe operation.

Excellent Waterproof Performance
The electrical and hydraulic systems are waterproof and sealed, effectively preventing moisture or rainwater from damaging critical components.

Flexible Mobility
The trailer-mounted design and compact structure facilitate transportation between multiple construction sites, requiring no complex installation, making it suitable for multi-site projects.

Precise Control
The PLC control system precisely adjusts pumping pressure and flow rate, ensuring concrete uniformity and reducing waste.

Parameter

Item(Small trailer concrete pump)	Unit	HBTS90-16-176R
Max. Theoretical Concrete Output(low/high pressure	m³/h	90/54
Max. Concrete Pumping pressure(Low/High pressure)	Mpa	9/16
Concrete slump	mm	100-230
Aggregate Size	mm	Pebble≤50 Gravel≤40
Engine Power	kw	176
Main oil pump	KAWASAKI
Hydraulic valve	BOLSEEN
Hydraulic hose	MANULI
Main electric element	SCHNEIDER
PLC Control computer	MITSUBISHI
Concrete Cylinder Diameter	mm	200/1800
Hopper Capacity	L	500
Filling Height	mm	1400
Max Theoretical Conveying Distance (Horizontal /vertical Height)	m	1400/270
Pipe Cleaning Mode		Water Washing
Dimension(transport)	mm	6700×2150×2500
Total Weight	kg	6700

Why Choose Us

Large-Scale Production Base
Our factory spans over 35,000 square feet with dedicated areas for processing, welding, assembly, painting, and machine testing, ensuring fast response to large-volume orders.

Professional Technical Team
With 300+ employees, including senior engineers and professional technicians, we provide design optimization, installation guidance, and operation training.

Advanced Equipment
CNC machining centers, plasma cutters, drilling machines, and grinders ensure precise parts and high-quality assembly.

Strict Quality Management
From raw materials to final testing, we maintain full control. Products are certified ISO9001, BV, and MA for mining safety.

FAQ

Q: What type of concrete pump is this Portable Concrete Pumping Machine?

A: This equipment is a trailer-mounted concrete pump, featuring a towed structure that combines excellent mobility with stable pumping performance, making it suitable for use across multiple construction sites.

Q: What are the requirements for concrete slump and aggregate size?

A: It is suitable for concrete with a slump of 100–230 mm, and a maximum aggregate size of ≤50 mm for pebbles and ≤40 mm for crushed stone, offering strong adaptability and reducing limitations on construction material mixing.

Q: What safety features does the equipment have?

A: The equipment is equipped with overload protection, an emergency stop button, and an automatic alarm system. It can shut down promptly in abnormal working conditions, effectively reducing operating risks and ensuring construction safety.

Q: Is it suitable for use in wet or rainy environments?

A: Yes. The electrical and hydraulic systems are designed with waterproof seals, effectively preventing moisture from entering critical components and ensuring stable operation in harsh environments.

Q: What specific application scenarios is it suitable for?

A: It is widely used in high-rise building construction, road and bridge engineering, industrial plant and warehouse construction, underground engineering, and tunnel construction, among other scenarios.
